DU-BRO 101: Installing A Universal Kwik Switch Mount

DU-BRO 101: Installing A Universal Kwik Switch Mount

The Universal Kwik-Swith Mount is a great accessory to simplify switching your receiver on or off. It comes with several parts to assemble in a specific order so let’s go over this carefully.

  • You’ll need a small flat-head screwdriver and an optional 5/16” wrench.
  • Determine how you want the switch to operate. Pull to turn on or pull to turn off. Orient the switch in the way you’d like and use the two included screws to mount your switch to the plate.
  • Determine where your mount will be placed by examining a location inside the fuselage that will be free of obstructions.
  • Drill a 3/16” hole in the location you’ve selected.
  • Install the guide tube in your hole and screw it into the mount, installing the switch. The optional 5/16” wrench can be used to tighten the guide tube.
  • Install the switch cap (plate) and then the push rod by screwing the rod into it. Verify that the switch fully operates and trim plastic where necessary.
  • I include a visual of the fully assembled switch mount for your reference.
